WS2812B全彩LED驱动, 代码实现了循环移动的流水灯点亮效果

标签: Arduino 开发教程  ESP32 学习笔记 电子电路  单片机
版权声明:本文为Lennon8_8原创文章,遵循 CC 4.0 BY-SA 版权协议,转载请附上原文出处链接和本声明。

今天心血来潮花了点时间写了个WS2812B的驱动,把灯点亮了。

WS2812B是一款全彩LED控制IC,单总线控制,信号时序如下图,其它信息请看规格书,要注意高低电平的时间一定要控制在规格书的要求范围内。WS2812B可以级联,每个灯接收的是24bit数据(GRB颜色值),D1灯在收到24bit数据后,会把数据保存,如果还收到数据,会通过DO脚传给D2

用STM32F0芯片,48M时钟,驱动代码如下:

头文件:

/************************************************************
Copyright (C), 2013-2020, XINZHIYIKONG.Co.,Ltd.
@FileName: WS2812B.h
@Author  : 糊读虫 QQ:570525287
@Version : 1.0
@Date    : 2020-12-25
@Description: WS2812B全彩LED灯驱动
@Function List:
@History    :
<author> <time> <version > <desc>

***********************************************************/

#ifndef __WS2812B_H
#define	__WS2812B_H

#include "stm32f0xx.h"
#include "sys.h"

//WS2812B IO 定义  注意初始化APB时钟也要修改
#define WS2812B_PORT		GPIOA
#define WS2812B_PIN			GPIO_Pin_15
#define WS2812B_RCC_AHB		RCC_AHBPeriph_GPIOA  //RCC时钟

#define WS2812B_Hi()		WS2812B_PORT->BSRR=WS2812B_PIN	//GPIO_ResetBits(LED1_PORT, LED1_PIN)
#define WS2812B_Low()		WS2812B_PORT->BRR=WS2812B_PIN	//GPIO_SetBits(LED1_PORT, LED1_PIN)

//颜色
typedef struct color{
	u8 G;
	u8 R;
	u8 B;
}Color_TypeDef;

//------------------------
#define PIXEL_NUM	59	//LED灯的个数

void WS2812B_Init(void);
void WS2812B_Reset(void);
void WS2812B_WriteColor(Color_TypeDef *pColor);
void WS2812B_RefreshPixel(void);

void WS2812B_FillColor(u16 start,u16 end,Color_TypeDef *pColor);
void WS2812B_MovePixel(u8 dir);

void WS2812B_Test(void);
#endif /* __WS2812B_H */


源文件

/************************************************************
Copyright (C), 2013-2020, XINZHIYIKONG.Co.,Ltd.
@FileName: WS2812B.c
@Author  : 糊读虫 QQ:570525287
@Version : 1.0
@Date    : 2020-12-25
@Description: WS2812B全彩LED灯驱动
@Function List:
@History    :
<author> <time> <version > <desc>

***********************************************************/

#include "WS2812B.h"

Color_TypeDef PixelBuf[PIXEL_NUM]; //像数数据
uint8_t flag;

//晶振48M,每个nop是20.83ns
#define DELAY_20_8nS		__nop()		//1个nop是20.8ns
#define DELAY_104nS			DELAY_20_8nS;DELAY_20_8nS;DELAY_20_8nS;DELAY_20_8nS;DELAY_20_8nS //5个nop是104ns
#define Delay_320nS()		DELAY_104nS;DELAY_104nS;DELAY_104nS  //30个nop

/*---------------------------------------------------------------------------
@Function   :Delay_850nS
@Description:检测开关初始化
@Input      :无
@Retrun     :无
@Others     :T1H T0L 时间在  580ns~1.6us,取850ns   实测855us
----------------------------------------------------------------------------*/
void Delay_850nS(void)
{
	//进入函数所用的时间约为310ns
	DELAY_104nS;
	DELAY_104nS;
	Delay_320nS();
	DELAY_20_8nS;
}
/*---------------------------------------------------------------------------
@Function   :Delay_300uS
@Description:
@Input      :无
@Retrun     :无
@Others     :
----------------------------------------------------------------------------*/
void Delay_300uS(void)
{
	uint8_t i;
	while(i--)
	{
		Delay_320nS();
	}
}

/*---------------------------------------------------------------------------
@Function   :WS2812B_Init
@Description:初始化
@Input      :无
@Retrun     :无
@Others     :
----------------------------------------------------------------------------*/
void WS2812B_Init(void)
{
	GPIO_InitTypeDef GPIO_InitStruct;
	RCC_AHBPeriphClockCmd(WS2812B_RCC_AHB, ENABLE);
	GPIO_InitStruct.GPIO_Pin = WS2812B_PIN ;
	GPIO_InitStruct.GPIO_Mode = GPIO_Mode_OUT;
	GPIO_InitStruct.GPIO_OType = GPIO_OType_PP;
	GPIO_InitStruct.GPIO_Speed =GPIO_Speed_Level_3;
	GPIO_Init(WS2812B_PORT, &GPIO_InitStruct);

	GPIO_SetBits(WS2812B_PORT, WS2812B_PIN);
}

/*---------------------------------------------------------------------------
@Function   :WS2812B_Reset
@Description:复位
@Input      :无
@Retrun     :无
@Others     :
----------------------------------------------------------------------------*/
void WS2812B_Reset(void)          //复位函数
{
	WS2812B_Low();
	Delay_300uS();
}

/*---------------------------------------------------------------------------
@Function   :WS2812B_WriteByte
@Description:写一个字节
@Input      :无
@Retrun     :无
@Others     :
----------------------------------------------------------------------------*/
void WS2812B_WriteByte(uint8_t dat)
{
	u8 i;
	for (i=0;i<8;i++)
	{
		//先发送高位
		if (dat & 0x80) //1
		{
			WS2812B_Hi();
			Delay_850nS(); //T1H
			WS2812B_Low();
			Delay_320nS(); //T1L
		}
		else	//0
		{
			WS2812B_Hi();
			Delay_320nS(); //T0H
			WS2812B_Low();
			Delay_850nS(); //T0L
		}
		dat<<=1;
	}
}


/*---------------------------------------------------------------------------
@Function   :WS2812B_WriteColor
@Description:写入1个24bit颜色数据
@Input      :无
@Retrun     :无
@Others     :
----------------------------------------------------------------------------*/
void WS2812B_WriteColor(Color_TypeDef *pColor)
{
	WS2812B_WriteByte(pColor->G);
	WS2812B_WriteByte(pColor->R);
	WS2812B_WriteByte(pColor->B);
}

/*---------------------------------------------------------------------------
@Function   :WS2812B_RefreshPixel
@Description:更新显示
@Input      :无
@Retrun     :无
@Others     :
----------------------------------------------------------------------------*/
void WS2812B_RefreshPixel(void)
{
	u8 i;

	for(i=0;i<PIXEL_NUM;i++)
	{
		WS2812B_WriteColor(&PixelBuf[i]);
	}
}

//----------------------------------------
void WS2812B_Test(void)
{
	u8 i;
	Color_TypeDef temp;
	temp.B = 0x50;
	temp.R = 0x60;
	temp.G = 0x70;

	for(i=0;i<60;i++)
	{
		WS2812B_WriteColor(&temp);
	}
}

//测试延时时间
void WS2812B_Test2(void)
{
	WS2812B_Hi();
	Delay_850nS();
	WS2812B_Low();
}

//============================================================================
void Copy_Color(Color_TypeDef *pDst,Color_TypeDef *pScr)
{
	pDst->R = pScr->R;
	pDst->G = pScr->G;
	pDst->B = pScr->B;
}

/*---------------------------------------------------------------------------
@Function   :WS2812B_FillColor
@Description:填充颜色
@Input      :start:开始位置;end:结束信置;pColor:颜色值
@Retrun     :无
@Others     :
----------------------------------------------------------------------------*/
void WS2812B_FillColor(u16 start,u16 end,Color_TypeDef *pColor)
{
	if (start > end) //交换位置
	{
		u16 temp;
		temp = start;
		start = end;
		end = temp;
	}

	if (start >= PIXEL_NUM)return; //超出范围
	if (end >= PIXEL_NUM)end = PIXEL_NUM-1;

	//填充颜色值
	while(start <= end)
	{
		Copy_Color(&PixelBuf[start],pColor);
		start++;
	}
}

/*---------------------------------------------------------------------------
@Function   :WS2812B_MovePixel
@Description:循环移动像素颜色
@Input      :dir:方向;
@Retrun     :无
@Others     :
----------------------------------------------------------------------------*/
void WS2812B_MovePixel(u8 dir)
{
	Color_TypeDef temp;
	u8 i;

	if (dir) //向左移动
	{
		Copy_Color(&temp,&PixelBuf[PIXEL_NUM-1]);

		i = PIXEL_NUM-1;
		while(i)
		{
			 Copy_Color(&PixelBuf[i],&PixelBuf[i-1]);
			 i--;
		}
		Copy_Color(&PixelBuf[0],&temp);
	}
	else  //向右移动
	{
		Copy_Color(&temp,&PixelBuf[0]);

		i = 0;
		while(i < (PIXEL_NUM-1))
		{
			Copy_Color(&PixelBuf[i],&PixelBuf[i+1]);
			i++;
		}
		Copy_Color(&PixelBuf[PIXEL_NUM-1],&temp);
	}
}

//----------------------------------END OF FILE------------------------------

/*---------------------------------------------------------------------------
@Function   :main
@Description:主函数
@Input      :
@Retrun     :无
@Others     :
----------------------------------------------------------------------------*/
int main(void)
{
	Color_TypeDef temp;
	HardWare_Init();

	WS2812B_Init();
	temp.R = 0x00;
	temp.G = 0xff;
	temp.B = 0x80;
	WS2812B_FillColor(10,20,&temp);
	while(1)
	{
		if (SysGetSignal_ms(20,0)) //20ms
		{
			WS2812B_MovePixel(1);
			WS2812B_RefreshPixel();
		}
	}
}

代码实现了循环移动的流水灯功能,点亮效果:
