WS2815 12V单点单控 内置IC全彩灯条 断点续传 全新升级
产品名称:WS2815-12V-60灯全彩跑马灯带
产品型号:WTP-WS2815-12V-60LED
工作电压:DC12V
芯片规格:WS2815,内封型,60颗/米
灯珠数量:60灯/米
灯珠类型:SMD5050-RGB
基板规格:2盎司双层FPCB(柔性软板), 板宽10mm, 白色/黑色
额定功率:12W
标准包装:5米/卷,铝箔袋防静电包装
每盘重量:240g(滴胶) 100g(裸板) 200g(套管)
防水级别:IP20/IP65/IP67/IP68可选
工作温度:-40℃~ 70℃
贮存温度:-50℃~ 80℃
光源寿命:50000小时
接线方式:4PIN端子连接器 (红线=12V供电,绿线=信号线DI,黄线=备用信号线BI, 黑线=GND地线 )
LED WS2815幻彩灯条应用范围:
该产品光源色彩丰富鲜艳、能见度高、更具有视觉吸引力。被广泛应用于墙体走廊,室内环境装饰,产品模型灯光装饰,游戏机灯光装饰,音箱灯光装饰,娱乐场所,酒柜吧台背光,天花背光,LED灯箱光源,LED发光牌,水族用品,汽车装饰等等,是取代传统霓虹灯、荧光灯和灯管的新一代照明光源。
